Dexter 10 x 2-1/4 Inch Hydraulic Trailer Brake Assembly, Right Hand, 3.5K, Manual Adjust - 023-609-00

The Dexter 023-609-00 is a complete 10 x 2-1/4 inch hydraulic trailer brake assembly built for the right-hand (RH) side of a 3,500 lb (3.5K) rated trailer axle. This is a full brake assembly rather than a single component, so it is intended as a direct replacement for a worn or damaged right-hand hydraulic brake on trailers within the Dexter 3.5K brake size family.

This unit uses a manual-adjust design, meaning brake shoe clearance is set by hand rather than through a self-adjusting mechanism, so periodic manual adjustment is part of normal maintenance for this brake. It is designated specifically for the right-hand side of the trailer; it is not interchangeable with a left-hand brake, which is a separate part.

Because this is sold as a complete assembly, it is intended to simplify replacement by supplying the full 10 x 2-1/4 inch hydraulic brake unit in one part rather than requiring separate sourcing of individual components.

Specifications

• Brand: Dexter
• Manufacturer Part Number: 023-609-00
• UPC: 023-609-00
• Category: Trailer Drum Brakes
• Brake Size: 10 x 2-1/4 inches
• Brake Type: Hydraulic
• Side: Right Hand (RH)
• Axle Capacity: 3,500 lb (3.5K)
• Adjustment Type: Manual Adjust (US Man Adj)
• Assembly Type: Complete assembly
• Weight: 8.76 pounds

Fitment

Fits trailer axles using the Dexter 10 x 2-1/4 inch, 3,500 lb hydraulic brake size on the right-hand side only.

Replaces (OEM)

No cross-reference numbers are specified for this part.

Frequently Asked Questions

Is the Dexter 023-609-00 a complete brake assembly or a single part? The 023-609-00 is sold as a complete 10 x 2-1/4 inch hydraulic trailer brake assembly, not a single individual component.

Does this brake fit the left or right side of the trailer? This is the right-hand (RH) specific brake assembly. It is not for left-hand installation; the left-hand version is a separate part.

What axle capacity is the Dexter 023-609-00 rated for? It is rated for 3,500 lb (3.5K) trailer axles.

Is this a hydraulic or electric trailer brake? The 023-609-00 is a hydraulic brake assembly.

What size brake shoes does the 023-609-00 use? It is built in the 10 x 2-1/4 inch brake size.

Does the Dexter 023-609-00 self-adjust? No. It uses a manual-adjust design, so brake shoe clearance must be set by hand rather than automatically.

How much does the Dexter 023-609-00 weigh? The complete assembly weighs 8.76 pounds.

Can the right-hand 023-609-00 be installed on both sides of the trailer? No. It is designated for the right-hand side only and should not be used in place of a left-hand brake.

What category of trailer part is the 023-609-00? It falls under trailer drum brakes, specifically as a complete hydraulic brake assembly.

Is routine maintenance required on the Dexter 023-609-00? Yes. Because it uses a manual-adjust mechanism, periodic manual adjustment of the brake shoes is part of normal upkeep.
