JIF Marine 4-Step Stationary Dock Ladder, Anodized Aluminum, 48 Inch

The JIF Marine DJV4 is a 4-step stationary dock ladder built for permanent mounting at the edge of a dock. It is constructed of 6005-T5 anodized aluminum, which is rated 22% stronger than the standard 6063 marine-grade aluminum used on many competing ladders, giving it added corrosion resistance and a longer service life in wet, saltwater, or freshwater dock environments. The ladder uses a fully welded, 2-piece design with no gap welding on the steps or other structural parts, so there are no weak points where corrosion or stress cracks can start. The handles are bolt-on and removable for storage or shipping, while the steps are fully welded and assembled using 2,000 lb clear factor stainless steel bolts for a secure, long-lasting connection.

The ladder measures 48 inches from the top of the dock to the bottom step, with a ladder width of 20 inches, a handle depth of 14 inches, and a step depth of 2 inches. The 4 steps are spaced 12 inches apart, and mounting bolt holes are 1/2 inch in diameter. The ladder is rated to hold up to 750 lbs, making it suitable for regular use by boaters and swimmers accessing the dock. This is a stationary, non-folding design intended for fixed dock installation rather than boat-mounted or telescoping applications.

Specifications

• Brand: JIF Marine
• Manufacturer Part Number: DJV4
• Product Name: 4-Step Stationary Dock Ladder
• Number of Steps: 4
• Material: 6005-T5 Anodized Aluminum
• Color/Finish: Silver
• Overall Height (top of dock to bottom of ladder): 48 inches
• Ladder Width: 20 inches
• Handle Depth: 14 inches
• Step Height (spacing between steps): 12 inches
• Step Depth: 2 inches
• Mounting Bolt Hole Diameter: 1/2 inch
• Weight Capacity: 750 pounds
• Weight: 22 pounds
• Special Feature: Stationary
• Assembly: 2-piece, UPS shippable
• Hardware: Stainless steel bolts, 2000 lb clear factor

Frequently Asked Questions

How many steps does the JIF Marine DJV4 dock ladder have? The DJV4 has 4 steps, spaced 12 inches apart from each other.

What is the overall height of this dock ladder? From the top of the dock to the bottom step, the JIF Marine DJV4 measures 48 inches.

What material is the DJV4 dock ladder made from? It is made of 6005-T5 anodized aluminum, which is rated 22% stronger than the standard 6063 marine-grade aluminum used in many other dock ladders, giving it better corrosion resistance.

How much weight can this ladder hold? The JIF Marine DJV4 has a weight capacity of 750 pounds.

Is this ladder foldable or stationary? The DJV4 is a stationary ladder, designed for fixed, permanent mounting at the dock edge rather than folding or retracting.

How wide is the ladder and how deep are the handles and steps? The DJV4 has a ladder width of 20 inches, a handle depth of 14 inches, and a step depth of 2 inches.

What size are the mounting bolt holes? The mounting bolt holes on the JIF Marine DJV4 are 1/2 inch in diameter.

How much does the dock ladder weigh? The JIF Marine DJV4 weighs 22 pounds.

Are the handles removable? Yes, the handles on the DJV4 are bolt-on and removable, while the steps are fully welded and assembled with 2,000 lb clear factor stainless steel bolts.

Does the ladder have any welded gaps that could weaken it? No. The DJV4 uses a fully welded, 2-piece design with no gap welding on the steps or other parts, reducing points where corrosion or cracking could start.

Can the DJV4 be shipped assembled? The ladder ships as a 2-piece, UPS shippable design, built for easy transport while remaining a fully welded, strong structure once installed.
