Moeller Three-Way Female Brass Fuel Valve, 1/4 in. NPT, Dual-Tank Selector, Part 033302-10

The Moeller 033302-10 is a three-way female brass fuel valve built to let a boat draw fuel from one of two permanent tanks at a time through a single line to the engine. It connects two permanent fuel tanks to one motor, with the valve position controlling which tank is feeding the engine, so you never draw from both tanks simultaneously. The valve body and ports are brass for corrosion resistance in a marine fuel system, and all three ports use 1/4 in. Female NPT threads for a direct threaded connection to standard 1/4 in. Fuel line fittings.

This valve meets ABYC H-24, the American Boat and Yacht Council standard covering gasoline fuel systems, so it is built to the dimensional and material expectations marine surveyors and installers check for. It is sold as a single unit and is intended as a manual fuel-source selector for dual-tank boats, replacing a worn or leaking three-way valve or adding tank-selection capability to a twin-tank fuel system.

Specifications

• Brand: Moeller
• Manufacturer Part Number: 033302-10
• Product Type: Three-Way Female Brass Valve
• Valve Type: Three-way
• Number of Ports: 3
• Thread Size: 1/4 in. NPT
• Thread Type: Female (all ports)
• Inlet Connection Size: 0.25 inches
• Outlet Connection Size: 0.25 inches
• Outlet Connection Type: FNPT
• Material: Brass
• Exterior Finish: Brass
• Specification Met: ABYC H-24
• Package Height: 2.1 inches
• Package Length: 4.5 inches
• Package Width: 2.8 inches
• Weight: 0.4 pounds
• Unit Count: 1
• UPC: 739729028537

Fitment

Universal 1/4 in. NPT dual-tank fuel systems; not engine- or model-specific.

Frequently Asked Questions

What does the Moeller 033302-10 three-way valve do? It lets a boat draw fuel from one of two permanent fuel tanks at a time, connecting both tanks to a single line feeding the engine so you can select which tank is in use.

Can I draw from both tanks at once with this valve? No. The Moeller 033302-10 is designed for withdrawal from one tank at a time only; it does not blend or combine flow from two tanks simultaneously.

What thread size does the 033302-10 use? All three ports on the Moeller 033302-10 are 1/4 in. Female NPT threads.

What is the valve body made of? The Moeller 033302-10 three-way fuel valve is made of brass, chosen for corrosion resistance in marine fuel systems.

Does this valve meet any marine fuel system standards? Yes, the Moeller 033302-10 meets ABYC H-24, the American Boat and Yacht Council standard for gasoline fuel systems.

How much does the 033302-10 weigh? The Moeller 033302-10 weighs 0.4 pounds.

What are the package dimensions of this valve? Packaged, the Moeller 033302-10 measures 4.5 inches long, 2.8 inches wide, and 2.1 inches tall.

Is this valve specific to one engine or boat model? No. The Moeller 033302-10 is a universal 1/4 in. NPT fuel selector valve for dual-tank systems and is not tied to a specific engine or boat model.

How many valves come in the package? One Moeller 033302-10 three-way brass valve is included per package, along with its threaded fittings.

Does the 033302-10 have a detent or click-stop position? No. The Moeller 033302-10 is the standard 1/4 in. NPT three-way valve without a detent; Moeller also makes a 1/4 in. NPT version with a detent under a different part number for buyers who want that feature.

Is a 3/8 in. NPT version of this valve available? Moeller offers a 3/8 in. NPT three-way valve as a separate part number for larger fuel line fittings, in addition to the 1/4 in. NPT 033302-10.
