Perko 0228DP0CHR Horizontal Mount Bi-Color Side Light, Chrome Finish

The Perko 0228DP0CHR is a horizontal-mount bi-color side light that combines red and green navigation lenses into a single low-profile housing. It is certified for use on power driven vessels under 65.6 feet (20 meters) in length, making it a standard choice for the running-light requirements of most recreational boats.

The light features a chrome-plated zinc alloy top mounted on a black plastic base, giving it a durable, corrosion-resistant finish suited to marine environments while keeping the base lightweight. It runs on a 12 volt system, uses an incandescent light source, and is built waterproof for continuous exposure on deck. The compact housing measures 3-1/4 inches in length, 2-5/16 inches in width, and 5/8 inches in vertical height, making it easy to fit into horizontal mounting locations on the bow or cabin where a low-profile light is needed.

As a bi-color unit, the 0228DP0CHR shows red to port and green to starboard from a single fixture, simplifying installation compared to running separate port and starboard lights. Installation instructions and technical drawings for this light are available directly from Perko.

Specifications

• Brand: Perko
• Manufacturer Part Number: 0228DP0CHR
• Style: Bi-Color (Red/Green)
• Finish: Chrome-plated zinc alloy top
• Base Material: Black plastic
• Length: 3-1/4 inches
• Width: 2-5/16 inches
• Vertical Height: 5/8 inches
• Weight: 0.6 pounds
• Voltage: 12 Volts
• Light Source: Incandescent
• Lens Colors: Red, Green
• Special Feature: Waterproof
• Vessel Length Certification: Under 65.6 feet (20 meters)
• OEM Equivalent Part Number: PKO0228DP0CHR
• Vehicle Service Type: Boat

Fitment

Certified for power driven vessels under 65.6 feet (20 meters) in length.

Replaces (OEM)

• PKO0228DP0CHR

Frequently Asked Questions

What size boat is the Perko 0228DP0CHR side light certified for? The 0228DP0CHR is certified for use on power driven vessels under 65.6 feet (20 meters) in length.

What are the dimensions of this side light? The Perko 0228DP0CHR measures 3-1/4 inches in length, 2-5/16 inches in width, and 5/8 inches in vertical height.

What is the housing made of? It has a chrome-plated zinc alloy top mounted on a black plastic base.

Does the 0228DP0CHR show both red and green light? Yes, it is a bi-color light, displaying red and green from a single horizontal-mount housing.

What voltage does the 0228DP0CHR run on? This side light operates on a 12 volt system.

Is the Perko 0228DP0CHR waterproof? Yes, the 0228DP0CHR is built waterproof for marine deck use.

What type of bulb does it use? The 0228DP0CHR uses an incandescent light source.

How much does the 0228DP0CHR weigh? It weighs 0.6 pounds.

Is there an OEM equivalent part number for the 0228DP0CHR? Yes, the OEM equivalent part number is PKO0228DP0CHR.

Is this light mounted horizontally or vertically? The 0228DP0CHR is a horizontal-mount side light, designed for a low-profile installation.

Where can I find installation instructions for the 0228DP0CHR? Installation instructions and technical drawings for the 0228DP0CHR are available directly from Perko.
