Sea-Dog Semi-Concealed Offset Cabinet Hinge 201914-1, 304 Stainless Steel, 2-3/16 x 2-3/4 Inch

The Sea-Dog 201914-1 is a semi-concealed offset hinge built for cabinet and locker doors on boats, RVs, and other marine or marine-grade applications. It is stamped from corrosion-resistant 304 stainless steel, making it suitable for the damp, salt-exposed environments typical of onboard cabinetry, galley cabinets, and storage lockers.

This hinge mounts on the back surface of the door and pairs with a 3/8 inch offset that is mortised into the edge of the door, keeping the door flush while allowing it to swing clear of the frame. The hinge measures 2-3/16 inches by 2-3/4 inches, with a 1/16 inch material thickness, and installs using five #6 RH screws (fasteners are not included). Each hinge weighs 0.152 pounds.

Because it is a semi-concealed design, part of the hinge remains visible on the door face while the offset portion tucks into the mortised edge, giving a cleaner look than a fully exposed surface-mount hinge without the extra fitting work of a fully concealed hinge.

Specifications

• Brand: Sea-Dog
• Manufacturer Part Number: 201914-1
• Type: Semi-Concealed Offset Hinge
• Material: 304 Stainless Steel
• Finish: Unfinished
• Dimension A (Length): 2-3/16 inches
• Dimension B (Width): 2-3/4 inches
• Dimension C (Thickness): 1/16 inch
• Dimension D: 1-1/2 inches
• Dimension E (Door Offset): 3/8 inch
• Dimension F: 1/2 inch
• Weight: 0.152 pounds
• Standard Pack: 10 each / 10 pair
• Fastener: Five #6 RH screws (not included)
• Mounting Type: Door Mount
• UPC: 035514201155

Fitment

Fits cabinet or locker doors designed for a semi-concealed offset hinge with a 3/8 inch mortised offset on the door edge; universal application, not model-specific.

Frequently Asked Questions

What is the Sea-Dog 201914-1 hinge used for? It is a semi-concealed offset hinge designed for mounting on the back surface of cabinet or locker doors, commonly used on boat galley and storage cabinetry.

What material is the 201914-1 hinge made from? It is stamped from 304 stainless steel, chosen for its corrosion resistance in damp or salt-exposed environments.

What are the dimensions of this hinge? The 201914-1 measures 2-3/16 inches long by 2-3/4 inches wide, with a material thickness of 1/16 inch.

How much does the 201914-1 hinge weigh? Each Sea-Dog 201914-1 hinge weighs 0.152 pounds.

Does the door need to be modified to install this hinge? Yes, the door edge needs a 3/8 inch offset mortised into it to correspond with the hinge, since this is a semi-concealed offset design rather than a surface-mount hinge.

What screws are needed to install the 201914-1? Installation requires five #6 RH screws, which are not included with the hinge.

Is this hinge fully hidden when the door is closed? No, it is a semi-concealed design, meaning part of the hinge remains visible on the door surface while the offset portion is mortised into the door edge; a fully hidden option would be a flush mount concealed hinge instead.

Does this hinge come in a finish other than stainless steel? The 201914-1 is stainless steel; a polished brass version with the same 2-3/16 by 2-3/4 inch dimensions is offered as a separate part number for buyers who prefer that finish.

Is the 201914-1 sold as a single hinge or a pair? It is packed in standard quantities of 10 each or 10 pair, so check the listing quantity to confirm how many hinges are included in the specific unit being ordered.

What is the mounting type for this hinge? The Sea-Dog 201914-1 is a door-mount hinge that attaches to the back surface of the cabinet door.
