Sea-Dog 221840-1 Hatch Cover Pull, Pull Only, Stamped 304 Stainless Steel

The Sea-Dog 221840-1 Hatch Cover Pull is a simple, low-profile pull designed to open deck-mounted access hatches on a boat. It is the Pull Only version, made from stamped 304 stainless steel for corrosion resistance in harsh marine conditions. The flange pull measures 1-1/4 inches in diameter and 1/8 inch thick, and the pull installs into a 3/16 inch hole cut into the hatch cover.

Installation is straightforward: the pull mounts through the prepared hole and is secured with a stainless steel washer for a tight, secure fit. A rubber gasket is used with the pull to cut down on rattling and help resist water penetration, though this listing covers the pull component only. Commonly used on deck hatches, this pull combines a clean, attractive appearance with the durability needed for regular exposure to sun, salt, and water. Because it is stamped 304 stainless steel, it resists rust and corrosion far better than plated steel hardware over the life of the boat.

Specifications

• Brand: Sea-Dog
• Manufacturer Part Number: 221840-1
• Type: Hatch Cover Pull, Pull Only
• Material: Stamped 304 Stainless Steel
• Flange Diameter: 1-1/4 inches
• Flange Thickness: 1/8 inch
• Overall Diameter: 1-15/16 inches
• Mounting Hole Diameter Required: 3/16 inch
• Weight: 0.078 pounds
• UPC: 035514221320

Frequently Asked Questions

What size hole do I need to drill for the Sea-Dog 221840-1 hatch cover pull? The Sea-Dog 221840-1 hatch cover pull requires a 3/16 inch hole for installation.

What material is the 221840-1 hatch cover pull made from? It is made from stamped 304 stainless steel, which resists corrosion in harsh marine conditions.

Does this listing include the rubber gasket? No, the 221840-1 is the Pull Only version and does not include the rubber gasket.

What are the dimensions of the flange on this hatch pull? The flange pull on the Sea-Dog 221840-1 measures 1-1/4 inches in diameter and 1/8 inch thick.

How much does the Sea-Dog 221840-1 hatch cover pull weigh? The 221840-1 hatch cover pull weighs 0.078 pounds.

What is this hatch pull typically used for? It is commonly used on deck-mounted access hatches to provide a simple, secure way to open the hatch.

Is a rubber gasket needed with this pull? A rubber gasket is used with the 221840-1 pull to reduce noise and resist water penetration, though it is sold separately from this Pull Only item.

What is the overall diameter of the 221840-1 pull? The Sea-Dog 221840-1 has an overall diameter of 1-15/16 inches.

Is the Sea-Dog 221840-1 corrosion resistant? Yes, because it is constructed of stamped 304 stainless steel, the 221840-1 hatch cover pull resists corrosion in saltwater and marine environments.

How is the hatch cover pull secured once installed? The Sea-Dog 221840-1 installs with a stainless steel washer that provides a tight, secure fit in the mounting hole.
