Sea Dog Side Mount Deck Hinge 270250-1, 316 Stainless Steel, 1/4 Inch Pin, 7/8 x 2 Inch Base

The Sea Dog Side Mount Deck Hinge 270250-1 is a 2-hole stainless steel hinge fitting designed to mount vertically on deck and attach an eye end in Bimini top applications. It is built from investment cast 316 stainless steel, giving it strong resistance to saltwater corrosion and long-term durability in marine environments. The hinge has a 7/8 inch x 2 inch base and accepts a 1/4 inch pin, and it ships with the matching 0P27006 pin/screw. Installation is done with number 10 flat head fasteners, which are not included, allowing the hinge to be securely fastened to a flat deck or mounting surface.

This fitting is part of Sea Dog's Side Mount Hinge Fittings line, which is used to create a pivoting connection point for Bimini top eye ends and similar canvas or frame hardware. The unfinished stainless steel construction gives it a clean silver finish that matches other stainless deck hardware. A heavier duty version of this hinge, the 270255-1, is also available with a larger 1-7/8 inch x 2-13/16 inch base and 5/16 inch pin for applications requiring a larger connection point.

Specifications

• Brand: Sea Dog
• Manufacturer Part Number: 270250-1
• Material: Investment Cast 316 Stainless Steel
• Base Size: 7/8 inch x 2 inch
• Pin Size: 1/4 inch
• Pin/Screw Part Number: 0P27006
• Fastener Type: Number 10 flat head (not included)
• Mounting Type: Side mount, deck
• Hole Count: 2 holes
• Finish: Unfinished
• Color: Silver
• Product Dimensions: 2 inches L x 0.88 inches W
• Weight: 0.16 pounds
• UPC: 035514270168
• Package Quantity: 1

Fitment

Designed for vertical mounting to attach an eye end in Bimini top applications; universal fit, not model-specific.

Frequently Asked Questions

What is the Sea Dog 270250-1 used for? The Sea Dog Side Mount Deck Hinge 270250-1 is used to mount vertically on a boat deck and attach an eye end in Bimini top applications, giving the top frame a pivoting connection point.

What material is the 270250-1 hinge made from? It is made from investment cast 316 stainless steel, which resists corrosion in saltwater and marine environments.

What size pin does this hinge use? The 270250-1 accepts a 1/4 inch pin, and the matching 0P27006 pin/screw is included with the hinge.

What are the base dimensions of the Sea Dog side mount deck hinge? The base measures 7/8 inch by 2 inch, with 2 mounting holes for attachment to the deck.

Are mounting fasteners included with the 270250-1? No. The hinge installs with number 10 flat head fasteners, which are sold separately.

How much does the Sea Dog 270250-1 deck hinge weigh? This hinge weighs 0.16 pounds.

What finish does the 270250-1 have? The Sea Dog 270250-1 has an unfinished stainless steel finish with a silver appearance.

Is the 270250-1 the same as the 270255-1 hinge? No, they are different parts. The 270250-1 has a 7/8 inch x 2 inch base with a 1/4 inch pin, while the 270255-1 is a heavy duty version with a larger 1-7/8 inch x 2-13/16 inch base and a 5/16 inch pin.

How many hinges come in one package? The Sea Dog 270250-1 is sold with a package quantity of 1 hinge.

Does the 270250-1 hinge mount horizontally or vertically? It is designed to mount vertically on the deck to attach an eye end in Bimini top applications.

What is the UPC for the Sea Dog Side Mount Deck Hinge 270250-1? The UPC for the 270250-1 is 035514270168.
