Sea-Dog Drain Tube 520320-1, HDPE, White, Adjustable for Motorwell, Livewell, and Baitwell Drains

The Sea-Dog Drain Tube (520320-1) removes water and other fluids from motor wells, livewells, and baitwells, giving boat owners a simple, leak-proof way to keep these compartments dry. It is constructed of durable, impact-resistant injection molded HDPE, a material chosen for its resistance to cracking and corrosion in the wet, high-exposure environments where drain fittings are used.

The tube is flanged 90 degrees on one end and is designed to fit standard 1 inch diameter mounting holes, giving it a clean, finished look once installed. Its adjustable length accommodates bulkhead installations ranging from 3/4 inch up to 2-1/2 inches thick, so it fits a range of deck and hull thicknesses without needing to be cut or modified. A locking drain tube nut threads down to create a tight, leak-proof seal against the bulkhead, and because the tube telescopes to length, no flaring tools are needed during installation, which saves setup time compared to fixed-length tubing.

This drain tube is designed for use with snap handle and T-handle drain plugs, making it a straightforward fit for common livewell and baitwell drain plug setups. It is finished in white; Sea-Dog also offers this same drain tube design in black ABS for buyers who want a different material or color to match their boat's fittings.

Specifications

• Brand: Sea-Dog
• Manufacturer Part Number: 520320-1
• Material: HDPE (High-Density Polyethylene)
• Color: White
• Bulkhead Thickness Range: 3/4 inch to 2-1/2 inches
• Mounting Hole Diameter: 1 inch
• Overall Length: 2.5 inches
• Outside Diameter: 1.25 inches
• Wall Thickness: 0.110 inches
• Weight: 0.044 pounds
• UPC: 035514520560

Frequently Asked Questions

What is the Sea-Dog 520320-1 drain tube used for? It removes water and other fluids from motor wells, livewells, and baitwells, draining them through a standard 1 inch mounting hole in the bulkhead.

What size bulkhead thickness does this drain tube fit? The Sea-Dog 520320-1 has an adjustable length that fits bulkhead installations from 3/4 inch up to 2-1/2 inches thick.

What size hole do I need to drill for installation? This drain tube is designed to fit a standard 1 inch diameter mounting hole.

What material is the 520320-1 drain tube made from? It is made from durable, impact-resistant injection molded HDPE (high-density polyethylene).

Does this drain tube come in a color other than white? The 520320-1 is finished in white; Sea-Dog also makes the same drain tube design in black ABS as a separate part number for buyers who prefer that color and material.

Do I need flaring tools to install this drain tube? No flaring tools are needed. The adjustable-length design of the Sea-Dog drain tube lets you fit it to your bulkhead thickness without cutting or flaring.

Is the drain tube leak-proof once installed? Yes. A locking drain tube nut threads down onto the tube to create a tight, leak-proof seal against the bulkhead.

What kind of drain plug works with this tube? The Sea-Dog 520320-1 is designed for use with snap handle and T-handle drain plugs.

What is the overall length and diameter of this drain tube? The 520320-1 has an overall length of 2.5 inches and an outside diameter of 1.25 inches, with a nominal wall thickness of 0.110 inches.

How much does the Sea-Dog 520320-1 drain tube weigh? It weighs 0.044 pounds.

Is this drain tube flanged on both ends? No, the Sea-Dog 520320-1 is flanged 90 degrees on only one end, which sits against the bulkhead once installed.

Can this drain tube be used in a baitwell as well as a motor well? Yes, the 520320-1 is designed for use in motor wells, livewells, and baitwells alike.
