SeaStar SS14108 Back Mount Rack Steering System, 8-Foot Cable

The SeaStar SS14108 is a back mount rack steering system built around an 8-foot rotary steering cable with a quick connect adaptor, designed to install from behind the dash. The rack-style steering gear uses a long tubular metal housing rather than a diecast helm case, giving four turns lock-to-lock for precise, comfortable control at the helm. This system is suitable for virtually all power-assisted sterndrive and inboard boats running steering wheels up to 16 inches in diameter, making it a common upgrade or replacement for boats already fitted with power-assisted steering.

The quick connect adaptor on the cable end simplifies hookup at the helm during installation, reducing the time needed to swap out a worn or failing cable. The kit ships as a complete cable assembly finished in blue, built from metal construction for durability in a marine environment.

Specifications

• Brand: SeaStar
• Manufacturer Part Number: SS14108
• Type: Back mount rack steering system
• Cable Length: 8 feet
• Steering Cable Type: Rotary steering cable with quick connect adaptor
• Turns Lock-to-Lock: 4 turns
• Maximum Wheel Diameter: 16 inches
• Recommended Use: Power-assisted sterndrive and inboard boats
• Included Components: Cable
• Color: Blue
• Material: Metal
• Item Dimensions: 20 x 32 x 6 inches
• Weight: 10.62 pounds
• UPC: 731957092090

Fitment

• Virtually all power-assisted sterndrive and inboard boats
• Steering wheels up to 16 inches in diameter

Frequently Asked Questions

What is the SeaStar SS14108? The SS14108 is a SeaStar back mount rack steering system that includes an 8-foot rotary steering cable with a quick connect adaptor, designed to install from behind the dash.

How long is the steering cable on the SS14108? The cable length is 8 feet.

How many turns lock-to-lock does this steering system give? Four turns lock-to-lock, which SeaStar designed into the SS14108 rack steering system for precise, comfortable control.

What size steering wheel can I use with the SS14108? The SS14108 is suitable for steering wheels up to 16 inches in diameter.

Will the SS14108 work with my boat? This SeaStar rack steering system is suitable for virtually all power-assisted sterndrive and inboard boats, provided the steering wheel is 16 inches in diameter or smaller.

Is the SS14108 a rack and pinion or rotary helm system? It is a rack steering system, identifiable by the long tubular metal rack housing behind the dash rather than a rounded diecast helm case; the cable itself is a rotary steering cable with a quick connect adaptor.

What is included with the SeaStar SS14108? The SS14108 kit includes the steering cable; it is a back mount rack system intended for installation from behind the dash.

What material is the SS14108 made from? The SS14108 steering system is constructed of metal.

What color is the SS14108 cable assembly? The SeaStar SS14108 is finished in blue.

How much does the SS14108 weigh? The SeaStar SS14108 weighs 10.62 pounds.

What are the dimensions of the SS14108 as packaged? The SS14108 measures 20 x 32 x 6 inches.

Is the SS14108 designed for power-assisted engines? Yes, the SS14108 rack steering system is intended for power-assisted sterndrive and inboard engines.
