T-H Marine Thru-Hull Fitting TH-1200CP Straight 1-1/8 Inch Hose Chrome Plated

The T-H Marine TH-1200CP is a straight thru-hull fitting built for clean, direct pass-through plumbing connections on boats. It is sized for a 1-1/8 inch hose barb and finished with a chrome plated coating that gives the appearance of stainless steel or brass without the cost of solid metal fittings. This chrome finish is applied using T-H Marine's Brite Plate plating process, which was the first of its kind introduced to the marine market by T-H Marine and which also strengthens the underlying plastic part rather than just coating it. The TH-1200CP is molded from high-quality virgin material and is UV stabilized, so it is designed to hold its size and appearance in sun-exposed marine environments over time. T-H Marine works with major hose manufacturers to match hose barb specifications, so the 1-1/8 inch barb is built to create a secure connection and a trouble-free installation. The straight-through body design makes the TH-1200CP well suited to common marine plumbing runs such as livewell plumbing, baitwell circulation, and bilge discharge routing where a direct outlet is needed. It shares its core dimensions and 1-1/8 inch hose sizing with the black TH-1200 and white TH-1202 versions of this same straight thru-hull fitting, with the chrome finish being the distinguishing feature of the TH-1200CP. It is sold individually.

Specifications

• Brand: T-H Marine
• Manufacturer Part Number: TH-1200CP
• Product Type: Thru-Hull Fitting
• Style: Straight
• Finish: Chrome Plated
• Material: UV stabilized plastic, chrome plated (Brite Plate process)
• Hose Barb Size (D): 1-1/8 inches
• Dimension A: 1-3/4 inches
• Dimension B: 3-1/2 inches
• Dimension C: 1-3/4 inches
• Dimension E: 1-3/8 inches
• Color: Chrome
• Package Dimensions: 2 x 4 x 2 inches
• Weight: 0.2 pounds
• UPC: 733572014501

Frequently Asked Questions

What size hose does the TH-1200CP thru-hull fitting fit? The TH-1200CP is sized for a 1-1/8 inch hose barb (dimension D), matched to major hose manufacturer specifications for a secure connection.

Is the TH-1200CP a straight or angled thru-hull fitting? It is a straight thru-hull fitting, designed for direct pass-through plumbing runs rather than a 90 degree turn.

What material is the TH-1200CP made from? The TH-1200CP is molded from high-quality virgin plastic that is UV stabilized, then finished with a chrome plated coating through T-H Marine's Brite Plate process.

What are the overall dimensions of the TH-1200CP? The TH-1200CP measures 1-3/4 inches at dimension A, 3-1/2 inches at dimension B, 1-3/4 inches at dimension C, 1-1/8 inches at the hose barb (D), and 1-3/8 inches at dimension E.

How much does the TH-1200CP weigh? The TH-1200CP thru-hull fitting weighs 0.2 pounds.

What finish does the TH-1200CP have? It has a chrome plated finish, giving it the look of stainless steel or brass hardware while remaining a molded plastic fitting.

What is the Brite Plate process used on the TH-1200CP? Brite Plate is T-H Marine's chrome plating process for plastic thru-hulls; it was the first such process introduced to the marine market and also strengthens the plastic part, an innovation that won the NMMA MAATS Innovation Award in 2001.

What is the TH-1200CP typically used for? This straight 1-1/8 inch thru-hull fitting is commonly used for livewell plumbing, baitwell circulation, and bilge discharge routing on boats.

Is there an extended-length version of the TH-1200CP? Yes, the TH-1200XLCP is the extended-length chrome plated version with the same 1-1/8 inch hose barb sizing; it is a separate part number from the standard-length TH-1200CP.

How does the TH-1200CP differ from the TH-1200 or TH-1202? The TH-1200CP shares the same dimensions and 1-1/8 inch hose barb as the black TH-1200 and white TH-1202 straight thru-hull fittings; it differs only in its chrome plated finish.

Is the TH-1200CP sold individually or in a kit? The TH-1200CP straight thru-hull fitting is sold individually.

What is the UPC for the TH-1200CP? The UPC for the T-H Marine TH-1200CP thru-hull fitting is 733572014501.
